An intensive two-day course in geometrical Tolerancing, which follows on from, and builds upon, the Level 1 course.
Learn how to define more advanced datum structures.
Find out how to use the Least Material Condition modifier.
Discover how to use the Maximum Material Condition modifier with datum references (datum shift).
The course covers some of the more advanced concepts of geometrical tolerancing and its application and interpretation.
It is suitable for anyone who has completed the Level 1 course.
Duration
2 days (available for classroom or on-line delivery).
Who is it for?
Mechanical, production and design engineers, drawing office and inspection personnel.
Delegates are required to have completed the Level 1 course.
Geometrical Tolerancing to BS 8888 and ISO standards – Level 2
What does it cover?
Review of Level 1 material
Guidelines for working with Geometrical Tolerances
The GPS method
Different worlds or states
Association
Default association criteria for defining datums
Non-default association criteria for defining datums
Filtration
Size tolerances
default size definitions
non-default size definitions
Datums
situation features
datums based on single datum features
common datums based on aligned and non-aligned datum features
datums based on groups of datum features
datums based on complex surfaces
identifying situation features on drawings
datums based on contacting features
moving datum targets
The tolerance hierarchy
How location and orientation tolerances control form directly and indirectly.
Maximum Material Requirement
Review of Maximum Material Requirement applied to tolerance values
bonus Tolerance
Virtual Condition boundaries
Maximum Material Requirement applied to datums
‘datum shift’
datums based on Virtual Condition boundaries
Least Material Requirement
Projected tolerance zones
Tolerances applied to non-rigid components
Multiple tolerances applied to groups of features
To book a course, discuss possible dates, or for further information:
Contact us anytime for friendly, professional advice
