Introduction to Tolerance Stack Calculations

This course introduces the method for tolerance stack calculations.

Course Description:

This course introduces a structured method for performing one-dimensional tolerance stack calculations to support functional design, robust specification, and informed decision-making. Participants learn how to analyse the cumulative effect of tolerances across a component or assembly, predict variation, and assess whether a design can reliably meet functional requirements. The method requires no specialist software — calculations can be carried out using standard spreadsheet tools or even a pocket calculator. The course focuses on practical, real-world 1-D tolerance stacks, while also outlining the limitations of the method for more complex 2-D and 3-D analyses. The course is offered to align with ISO GPS or ASME Y14.5 depending on client preference.

Course Objectives:

By completing this course, participants will:

• Understand the purpose of tolerance stacks - Learn why tolerance analysis is essential for ensuring fit, function, performance, and manufacturability in components and assemblies.

• Apply a systematic 1-D stack method - Develop the ability to calculate tolerance accumulation in a single direction using a structured, repeatable process suitable for everyday engineering.

• Use common tools effectively - Perform stack calculations using spreadsheet software or simple calculators — no specialist software required.

• Analyse and refine designs - Use tolerance stacking to evaluate worst-case and statistical scenarios, and adjust dimensions or tolerances to achieve functional objectives.

• Recognise method limitations - Understand how 2-D stacks may require vector resolution into multiple 1-D stacks, and why full 3-D analyses require specialist software.

• Build practical engineering capability - Gain a practical toolset that can be applied to many real-world design and assembly tolerance problems, making this an essential skill for engineers working with critical dimensional relationships.

Who it is for:

This is our general course, designed to be accessible to participants from all industries — whether new to geometrical tolerancing or with prior experience.

The course is particularly valuable for:

• Design and Mechanical Engineers

• Inspectors and Inspection Planners

• Drafters

• Machinists, Operators, and Tooling Engineers

• Sales, Purchasing, and Quality personnel

• Managers, Supervisors, and Production Associates

• Anyone who needs to read, interpret, or work with the standards on engineering specification




Requirements:

• Delegates need a thorough understanding of engineering drawing, geometrical tolerancing and the Maximum Material Requirement. This course is normally run as a follow-on to the three day Geometrical Tolerancing (Fundamentals) course.

• Delegates need to bring laptops. All other materials are provided by GD&T Academy.

• An upper limit of 10 delegates is advised to ensure effective learning.

Materials provided:

• Detailed course notes including drawing examples

• Workbook with exercises and other printable handouts

• Quizzes and knowledge checks to gauge progress throughout the course

• Certificate of course completion

Delivery Format:

• Onsite or online delivery

Duration:

• 1 day

Course Syllabus:

• The tolerance stack concept.

• How to set up a tolerance stack calculation (objectives, conditions, the vector loop and the stack table).

• How to set up a stack for components with limit (+/-) tolerances.

• How to set up a stack for components with geometrical tolerances.

• How to take account of bonus tolerances.

• How to take account of datum shift.

• How to set up tolerance stacks for assemblies.
